Bench Top Water Ph Water Quality Analyzer

Get a Price/Quote

Product Details:

Number of Specimens Single Sample
Display Type Digital LCD
Port Size Standard BNC Electrode Connector
Features Automatic temperature compensation, calibration, compact design, easy operation
Accuracy 0.01 pH
Response Time 30 sec
Humidity 85% RH
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

Bench Top Water Ph Water Quality Analyzer Price And Quantity

Protection Class IP54
Operating Environment Laboratory, Industrial, Research
pH Electrode Type Combined glass electrode (included)
Electrode Stand Included
Input Impedance >10^12
Buffer Solution Calibration Up to 3-point auto calibration
Temperature Compensation 0-100C (Manual/Automatic selectable)
mV Measurement Range -1999 mV to +1999 mV
Data Storage Up to 50 sets

Bench Top Water Ph Water Quality Analyzer Product Specifications

Resolution 0.01 pH
Frequency 50Hz
Interface Type RS232 or USB (depends on model)
Control Mode Manual & Automatic
Equipment Type Bench Top Water pH Water Quality Analyzer
Test Range 0.00 14.00 pH
Measuring Range pH: 0.00 ~ 14.00
Temperature 5C 40C
Usage Laboratory / Water Analysis
Power Supply AC 220V 10%, 50Hz
Mounting Type Table Top
Application Water quality, laboratory & industrial analysis
Port Size Standard BNC Electrode Connector
Display Type Digital LCD
Number of Specimens Single Sample
Machine Weight Approx 2.5 kg
Operating Voltage AC 220V
Humidity 85% RH
Automation Grade Automatic
Response Time 30 sec
Accuracy 0.01 pH
Features Automatic temperature compensation, calibration, compact design, easy operation

Protection Class IP54
Operating Environment Laboratory, Industrial, Research
pH Electrode Type Combined glass electrode (included)
Electrode Stand Included
Input Impedance >10^12
Buffer Solution Calibration Up to 3-point auto calibration
Temperature Compensation 0-100C (Manual/Automatic selectable)
mV Measurement Range -1999 mV to +1999 mV
Data Storage Up to 50 sets

Bench Top Water Ph Water Quality Analyzer Trade Information

Sample Available Yes
Main Export Market(s) North America, Middle East, Africa, Central America, Eastern Europe, Australia, South America, Western Europe, Asia
Certifications ISO Certification, MSME Certificate

Product Description

With the seamless involvement of technology and manpower, our organization is able to manufacture and export Water Quality Analyzer, which assures high efficiency and accuracy. Facilitated with digital LCD that makes it easier to read the results, these analyzers are used for evaluating the quality of the water in health & environmental supervising authorities and municipal water system authorities. We are offering this Water Quality Analyzer to our clients at market leading prices.

Features

Easy and excellent functions
Portable
Robust

Bench Top Water Ph Water Quality Analyzer

pH	Measurement method	Galass electorode method
	Measurement range	pH 0.000-14.000
	Display range	pH -2.000-19.999
	Resolution	0.001 pH
	Repeatability	+0.005 pH+1 digit
	pH calibration point	5
	Repeatability check
	Alarm limit of calibration
mV(ORP)	Measurement range	+1999.9 mV
	Resolution	0.1 mV
	Repeatability	+0.1 mV+1 digit
Temperature	Measurement range	0.0-100.0(-30.0-130.0)
	Resolution	0.1
	Repeatability	+0.1+1 digit
Input/output	Input(CH)	1
	USB peripherals (Communication with PC)*1
	RS-232C(Printer/PC)
Data	Memory number	999
	Interval memory
	ID input
Display		Custom LCD
Function	Printer connectivity+GLP/GMP
	temperature compensation Auto/manual)
	AutoHold function
	Security(pass word
	Version up function
Ambient temperature		0 - 45
Power		AC adaptor 100 - 240 V 50/60 Hz
Dimensions		170(W)x174(D)x73(H)mm(Excluding electrode stand and AC adaptor)
Power consumption		Approx. 0.7 VA
Mass of main unit		Approx. 500 g

High-Precision pH Measurement

Achieve consistent and reliable water quality data across a wide pH range (0.0014.00) with 0.01 pH accuracy. This device supports laboratory and industrial analysis, making it optimal for research, water treatment facilities, and quality control labs requiring stringent measurement standards.

Effortless Calibration and Data Management

The analyzer offers up to 3-point automatic buffer solution calibration for enhanced accuracy. With the capability to store up to 50 sets of results, users can easily review data for ongoing analyses, reducing manual recording errors and streamlining processes.

Robust and User-Friendly Design

IP54 protection, a sturdy electrode stand, and compact mounting simplify installation and operation. The digital LCD display presents clear results, while manual or automatic temperature compensation adapts to diverse sample environments, supporting consistent results under varying conditions.

FAQs of Bench Top Water Ph Water Quality Analyzer:

Q: How do I calibrate the Bench Top Water pH Water Quality Analyzer?

A: The analyzer supports up to 3-point automatic calibration using buffer solutions. Simply select the calibration mode, immerse the included glass electrode in the buffer solution, and follow the prompts on the digital LCD display for accurate calibration.

Q: What types of environments is this analyzer suitable for?

A: It is designed for laboratories, industrial sites, and research facilities. Its IP54 protection class and wide operating range (5C40C, 85% RH) ensure reliable performance in various settings where precise water pH measurement is required.

Q: When should I use manual versus automatic temperature compensation?

A: Manual compensation is preferred when working with samples at controlled temperatures, while automatic compensation is ideal for samples with fluctuating temperatures. The selectable mode ensures accurate pH readings regardless of environmental conditions.

Q: Where can the stored measurement data be accessed?

A: Up to 50 sets of measurement results are stored in the devices memory. Data can be reviewed directly on the LCD display or transferred to a computer using the RS232 or USB port, depending on the specific model.

Q: What process ensures accurate pH measurement with this device?

A: For highest accuracy, calibrate using fresh buffer solutions, perform temperature compensation, and ensure the combined glass electrode is properly cleaned before each use. Follow the manufacturers operating instructions to achieve 0.01 pH accuracy.

Q: How does the analyzer benefit water quality analysis?

A: It provides rapid response times (30 sec), high accuracy, and easy operation, making it ideal for routine water testing, quality control, and research. Automatic features streamline processes and minimize user error, supporting reliable data collection.
